JAXSR Documentation

JAXSR Documentation#

JAX-based Symbolic Regression

JAXSR is a Python library for discovering interpretable algebraic expressions from data using sparse optimization techniques.

Overview#

JAXSR provides tools for symbolic regression - the task of finding mathematical expressions that describe relationships in data. Unlike black-box machine learning methods, symbolic regression produces human-readable equations that can provide scientific insight.

Try it in your browser — nothing to install

Open the JAXSR web app

Upload a spreadsheet, say which columns are features and which is the response, choose the families of functions to consider, and get a ranked table of candidate equations with confidence intervals, ANOVA, diagnostic plots, and exports.

The whole library is compiled to WebAssembly and runs client-side, so nothing is uploaded and unpublished data never leaves your machine. The app offers an example workbook with a known answer to work through, and can export a Python script that reproduces your fit locally.

Key features:

  • Flexible Basis Functions: Build custom libraries of candidate functions

  • Multiple Selection Strategies: Choose from greedy, exhaustive, or LASSO-based methods

  • Uncertainty Quantification: Prediction intervals, Bayesian Model Averaging, conformal prediction, and bootstrap methods

  • Physical Constraints: Incorporate domain knowledge through constraints

  • Additive Symbolic Regression: Boosting-style ensembles of small symbolic expressions (jaxsr.additive)

  • JAX-Powered: GPU acceleration, JIT compilation, automatic differentiation

  • Scikit-learn Compatible: Familiar fit/predict interface

  • Two GUIs: a hosted browser app that needs no install, and a local Streamlit app for the full design-of-experiments cycle

Installation#

pip install jaxsr

For development:

git clone https://github.com/jkitchin/jaxsr.git
cd jaxsr
pip install -e ".[dev]"

Quick Start#

from jaxsr import BasisLibrary, SymbolicRegressor
import jax.numpy as jnp

# Create basis library
library = (BasisLibrary(n_features=2, feature_names=["x", "y"])
    .add_constant()
    .add_linear()
    .add_polynomials(max_degree=3)
    .add_interactions()
)

# Fit model
model = SymbolicRegressor(basis_library=library, max_terms=5)
model.fit(X, y)

# Results
print(model.expression_)
print(f"R² = {model.metrics_['r2']:.4f}")

Interactive apps#

Two graphical front ends, for different jobs.

Browser app — nothing to install. Best for fitting a dataset you already have, comparing candidate models, and sharing a result with someone who does not use Python. Runs on WebAssembly, so your data stays in the browser.

Streamlit DOE app — for the full experimental cycle, where you are choosing what to measure next rather than analysing a finished dataset:

pip install "jaxsr[app]"
jaxsr app                      # opens http://localhost:8501
jaxsr app --study my.jaxsr     # resume a saved study

Eight pages covering the loop end to end: define factors, generate a design and export an Excel template for the bench, import the completed results, fit, inspect diagnostics, explore the response surface, run canonical analysis and get suggested next experiments, then export a Word or Excel report. State persists in a .jaxsr study file, so a campaign can be picked back up later. See the Design of Experiments Guide.

Documentation Contents#

How It Works#

JAXSR follows the ALAMO (Automated Learning of Algebraic Models for Optimization) methodology:

  1. Basis Library Construction: Define a library of candidate basis functions (polynomials, transcendentals, interactions, etc.)

  2. Design Matrix Evaluation: Evaluate all basis functions on training data to create a design matrix Φ

  3. Sparse Selection: Use information criteria (BIC, AIC) to select a sparse subset of basis functions

  4. Coefficient Fitting: Fit coefficients via least squares, optionally with constraints

  5. Model Analysis: Examine Pareto front, export to various formats

When to Use JAXSR#

JAXSR is ideal when you:

  • Want interpretable models rather than black boxes

  • Have domain knowledge to constrain the solution space

  • Need to discover physical laws or empirical correlations

  • Require reproducible results (deterministic algorithms)

  • Want to explore the accuracy-complexity trade-off

Comparison with Other Tools#

Feature

JAXSR

ALAMO

PySR

GP

Open Source

✓

✗

✓

✓

Deterministic

✓

✓

✗

✗

UQ / Intervals

✓

Limited

✗

✗

Constraints

✓

✓

Limited

Limited

GPU Support

✓

✗

✓

Varies

License#

JAXSR is released under the MIT License.
